Automate your Welding

In an ever-changing industry, the EZ Weld is the ideal welder for your business. It is an easy-to-use, simple, and efficient tig welder that simplifies production by automating what was once a laborious task. With touchscreen controls and a simple interface, the EZ Weld provides fast training, easy operation, and high repeatability. The EZ Weld is also equipped with multiple safety features protecting your operators as well as continuous operation with dual work zones, providing the ultimate solution to work efficiency.

Key Features

  • SIMPLE

    Operations are quick and easy thanks to commands being positioned on the torch handle

  • Shape-detecting

    Autonomously detect sheet metal deformation without any programming activity by the operator

  • ±0.03mm precision

    Use of UR5e collaborative robot with 6 axes and 6 rotating DoF joints with +0.03mm (0.001 in) precision and payload

  • Control

    Touchscreen control interface with intuitive programming buttons make processes quick and simple

  • Easy Handling

    Compact structure volume and a limited weight make it easily repositionable using a common forklift or crane

  • Safety

    Equipped with 17 advanced, adjustable safely devices, including the continuous monitoring of the robot elbow

  • Working Area

    First robotic cell for TIG welding with a working range of 2400 mm x 1200 mm or 94.5 in x 47.2 in

  • Axis 6

    Axis on the robot and a 7th axis 1800 mm, that works in synchrony - ensuring maximum robot arm use and reduced encumbrance

Specifications

Due to a continuous product development program, engineering data and dimensions are subject to change without notice. Certified foundation plans will be furnished for each installation.

Description Specification/Scope of Supply
Cobot Universal Robot UR5e 6-Axis 33.5" reach
Welder Bohler Uranos NX 2700
Wire Feed Speed 0.5-22 m/min
Wire Diameter 0.6-1.6mm
Dust Collection 1,200 CFM portable weld fume extractor
Weld Tables 1200mm x 1200mm
Total Work Area 2400mm x 1200mm
Weight 2500kg (5,512lbs)
Approx. Footprint 3041mm (W) x 1736mm (D) x 2877mm (H)
Warranty 1 Year parts & service
Optional Extended Warranty Two year extended warranty available

Use 100+% Of your Workspace

With the unique design of the robotic arm, now you can use the entire enclosed workspace plus a little more.
