SAAM


Specifications

CINCINNATI® follows the policy of continuous advancement in product development. For this reason, specifications and dimensions are for reference only and can change without notice. Foundation plans are furnished with each new machine installation.

Printer Friendly Specifications

Technical Specifications

  • Build Envelope: 7.9” x 7.4” x 9.4” (200mm x 190mm x 240mm)

  • Part Ejection (Optional): Hardened steel blade assisted automatic unloading

  • Nozzle Temperature: 572°F (300°C)

  • Heated Bed Temperature: 212°F (100°C)

  • Nozzle: Hardened Steel

  • Z Resolution: 0.0004” (11 microns)

  • Part Accuracy (part accuracy is depending on geometry): 0.005” (125 micron)

  • Certified Materials: PLA, ABS, PETG, Nylon, Carbon-Fiber Nylon, Glass-Filled Nylon

  • Printer Dimensions: 21” x 17.5” x 23”

  • Construction: 6061 Aluminum and Steel Frame

  • Power Requirements: 100-240V, 50-60Hz, 2.5-3.5A


SAAM HT - Small Area Additive Manufacturing High Temperature

Specifications

CINCINNATI® follows the policy of continuous advancement in product development. For this reason, specifications and dimensions are for reference only and can change without notice. Foundation plans are furnished with each new machine installation.

Printer Friendly Specifications

Technical Specifications

  • Build Envelope: 7.9” x 7.4” x 9.4” (200mm x 190mm x 240mm)

  • Part Ejection (Optional): Hardened steel blade assisted automatic unloading

  • Max Nozzle Temperature: 932°F (500°C)

  • Max Bed Temperature: 482°F (250°C)

  • Certified Materials: PLA, ABS, PETG, Nylon, Carbon-Fiber Nylon, Glass-Filled Nylon, Polycarbonate, ULTEM 9085, CF ULTEM 1010, Glass-Filled PEEK, Bound Metal Powder

  • Construction: All Metal Insulated Enclosure

  • Z Resolution: 0.0004” (11 micron)

  • Part Accuracy (part accuracy is depending on geometry): 0.005” (125 micron)

  • Printer Dimensions: 30” x 22” x 23”

  • Power Requirements: 120 VAC, 2kW, Single Phase
