BAAM Specifications

 BAAM Specifications

CINCINNATI® follows the policy of continuous advancement in product development. For this reason, specifications and dimensions are for reference only and can change without notice. Foundation plans are furnished with each new machine installation

Printer Friendly Specifications


Specification Tables

BAAM Dimensions

Length (A) Width (B) Height (C) Weight Power
603 308” 144” 128” 32,000 lbs 460 V/
3 Phase/
60 Hz
606 308” 144” 171” 32,000 lbs
608 308” 144” 198” 32,000 lbs
806 427” 153” 172” 40,000 lbs

Workpiece Dimensions

X axis Y axis Z+W Axis
603 140” 65” 34”
606 140” 65” 72”
608 140” 65” 98”
806 240” 90” 72”
